Manufacturing Environment Technology Capabilities

  • Regular monitoring of particle counts
  • Air showers and positive pressure control environment
  • Ongoing benchmarking of airborne contamination through “patch” and “sedimentation” tests

  • Production facilities in Pottsville, PA, USA, and Guangzhou, China

Winding

  • Excellent flat profile wound rolls, without tin canning, flared edges and gauge banding
  • In-line wrinkle detection
  • Capability to produce up to 2.8 meters wide web
  • Capability to produce 15,000 linear meters per roll with no splices

Extrusion

  • Dedicated assets to accelerate product development and increase speed to market
  • Mono and three-layer cast coextrusion technologies

    • OSM (One Side Matte) – Matted / Embossed for ease of winding / unwinding
    • TSM (Two Side Matte) – Both sides of film matte-finished/ embossed
    • Films from 20 microns to 120 microns

  • Thinner films 20 microns and above

Packaging

  • Robust fastenerless packaging design for air and sea shipments as well as easy disassembly
  • Environmentally friendly returnable and reusable packaging

Differentiating Technology

Extrusion

  • Adhesiveless low tack film manufacturing process
  • Adjustable adhesion tack capability with low residual residue
  • Excellent surface finish to prevent transcription damage

Filtration

  • Ultra-fine filtration
  • Less than 1 gel (< 1mm) per 1,000 square meters with 95% confidence level

Detection and Characterization of Defects

  • In-line camera detection of surface flaws
  • Dark field technology to detect repeating defects
  • Reliable off-line dark room inspection capability

Product Development

Tredegar Surface Protection has a 25-year track record for providing high-quality films that protect layers of a Flat Panel Display. Additionally, we provide tapes for semiconductor die singulation and carrier applications. As the design cycles in the electronics industry have accelerated, Tredegar has expanded our research capabilities to advance these markets. Tredegar has invested in world-class manufacturing capabilities that empower development and speed commercial scaling of new products. In addition to direct in-house capabilities, Tredegar maintains broad specialized knowledge through its confidential partnerships with world-leading research professionals, companies, and educational institutions.

Our research capabilities include:

  • Dedicated manufacturing development line
  • Advanced analytical tools including cutting-edge microscopy
  • Surface science expertise
  • Extensive analytical and polyer characterization capabilities

Analytical Capabilities

Physical Property Characterization:

  • Mechanical: Strength, Elongation, Density, Basis Weight, Compressibility, Resilience, Free Shrinkage and Adhesion
  • Optical: Haze, Gloss, Opacity, and Transmission
  • Surface: CoF, Contact Angle, and Free Energy
  • Extended Use: Moisture, Thermal Aging, and Weathering

Extensive Analytical Expertise:

  • Thermal analysis: DSC and TGA
  • Rheological analysis: MFI, DMA, and DOR
  • Additive and resin analysis
  • Electron, Raman, IR and 3D optical microscopy
  • FTIR, ATR, XPS, Raman, and UV-VIS spectroscopy
  • Surface Science: TOF-SIMS and 3D profilometry
  • Trace Analysis: GC-MS, LC-MS, HPLC, ICP-MS, and ICP-OES

Extensive process experience and material knowledge enabling impeccable interpretation ability

Blown Film

Three (3) Blown HDPE Lines

  • Ultra-thin yet Strong and Capable Film
  • HMW-HDPE high stalk process enables down-gauging while providing the stiffness, flexibility and sealing properties needed for packaging.
  • MD orientation in the “stalk” balances properties and increases the strength.
  • Thin A-B-C co-ex structures match heavier conventional films.
  • Full circumference gauge profile and control.
  • Gravimetric blending, corona treatment, Surface/Layon pressure control winding.
  • Approximately 6,500 Metric Ton HD Annual Capacity including newly added Line 505.

Four (4) Blown LDPE Lines

  • Mono and Coex Capability
  • Circumference gauge profile and control
  • Gravimetric blending and corona treatment
  • Capable of up to 80” width in size.

Two (2) Cast Polypropylene Lines

  • Two main types of Cast Films Produced:

      • Flat Cast – “Smooth/Glass-like” Surface

    Matte Finish – Surface Enhancement

  • Thickness range of 1.0 to 10 mil (20.3-101.6 цm)
  • 24” to 87” wide (5.08-220 cm)
  • Up to 40” OD (101.6 cm)
  • Auto-profile gauging and control
  • Gravimetric blending
  • 6,000 MT Annual Capacity
